Marin Gestalt X10 700C Gravel Road Bicycle
Marin Gestalt X10 700C Gravel Road Bicycle
Low stock: 1 left
Couldn't load pickup availability
SKU:
Get ready for an adventure with the Gestalt X! This bike is perfect for both off-road and on-road riding, and is great for long distance commuting and gravel riding. It's got a super sturdy 1x drivetrain and big, beefy tires for tackling rough terrain, plus a dropper post for better control on the trails. And when you're ready to hit the road, the Gestalt X has got you covered with its stable descending capabilities. Whether you're tackling singletrack trails or cruising down the street, this bike is ready for action.
SPECIFICATIONS:
-
FRAME
Series 3 Beyond Road, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle
-
FORK
Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
-
RIMS
Marin Aluminum Double Wall, 19mm Inner, 24mm Tall, Disc Specific
-
HUB, REAR
Forged Aluminum Alloy, 32H
-
HUB, FRONT
Forged Aluminum Alloy, 32H
-
SPOKE, NIPPLES
14g Black Stainless Steel
-
TIRES
Schwalbe G-One Performance, 700Cx40mm, Folding Bead
-
DERAILLEUR, REAR
MicroSHIFT Advent X 10-Speed Wide-Range
-
DERAILLEUR, FRONT
-
-
SHIFT LEVER
MicroSHIFT Advent X 10-Speed
-
CRANKSET
Forged Alloy 1x10, Hollow CrMo Spindle, Narrow Wide 42T
-
BOTTOM BRACKET
External Sealed Cartridge Bearings
-
CHAIN
KMC X10
-
CASSETTE
SunRace 10-Speed, 11-51T
-
BRAKE, FRONT
Tektro MD-C500 Dual Piston Road Mechanical Disc, 160mm Rotor
-
BRAKE, REAR
Tektro MD-C500 Dual Piston Road Mechanical Disc, 160mm Rotor
-
BRAKE LEVERS
MicroSHIFT Advent X
-
HANDLEBAR
Marin Butted Alloy, Compact 16º Flared Drop
-
STEM
Marin 3D Forged Alloy
-
GRIPS
Marin Shock Absorbing Perforated Tape
-
HEADSET
FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”
-
SEATPOST
Marin Alloy, 27.2mm
-
SADDLE
Marin Beyond Road Concept
-
PEDALS
-
-
EXTRAS
Bolt-On Thru-Axles F and R
Specifications, pricing, and availability are subject to change without notice.
GEOMETRY
| 50 | 52 | 54 | 56 | 58 | 60 | |
|---|---|---|---|---|---|---|
| STACK | 548.6 | 564.7 | 578.8 | 599.7 | 618.7 | 639.4 |
| REACH | 373 | 373.1 | 373.5 | 387.3 | 401.8 | 410.6 |
| HEADTUBE ANGLE | 70.5° | 71° | 71° | 71.5° | 71.5° | 72° |
| HEADTUBE LENGTH | 120 | 135 | 150 | 170 | 190 | 210 |
| SEATTUBE ANGLE | 75° | 74° | 73.5° | 73.5° | 73.5° | 73.5° |
| SEATTUBE LENGTH | 450 | 470 | 490 | 510 | 530 | 550 |
| TOPTUBE EFFECTIVE | 520 | 535 | 545 | 565 | 585 | 600 |
| BB HEIGHT | 269 | 269 | 269 | 269 | 269 | 269 |
| BB DROP | 80 | 80 | 80 | 80 | 80 | 80 |
| CHAINSTAY | 415 | 415 | 415 | 415 | 415 | 415 |
| WHEELBASE | 999.2 | 1000.1 | 1005.4 | 1021.2 | 1036 | 1046.1 |
| STANDOVER HEIGHT | 583 | 666 | 694 | 714 | 727 | 747 |
| FORK OFFSET | 50 | 50 | 50 | 50 | 50 | 50 |
| SEATPOST DIAMETER | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 |
| HANDLEBAR WIDTH | 440 | 440 | 460 | 460 | 480 | 480 |
| STEM LENGTH | 70 | 70 | 70 | 70 | 90 | 90 |
| CRANK LENGTH | 170 | 170 | 175 | 175 | 175 | 175 |
All lengths in millimeters
What Size?
Finding the right size bicycle is essential for a comfortable and enjoyable ride. With various frame sizes, wheel sizes, and frame styles available, it's important to choose a bike that fits you well. Our sizing and geometry chart, detailing seat tube and top tube lengths, helps ensure optimal stand-over clearance and comfort. Strive for a riding position that's neither cramped nor stretched. Questions? Our expert team is here to assist in finding your perfect bike fit.
Kids Bikes Sizing Chart:
- Child's Height (Inches/Centimeters) | Wheel Size
- 2’9” - 3’1″ (85 - 90 cm) | 12 inches
- 3’1” - 3’3″ (90 - 100 cm) | 12/14 inches
- 3’3” - 3’7″ (100 - 110 cm) | 14/16 inches
- 3'7" - 3'8" (110 - 115 cm) | 16/18 inches
- 3’8” - 4’0″ (115 - 120 cm) | 18/20 inches
- 4'0” - 4’5″ (120 - 135 cm) | 20/24 inches
- 4'5" - 4'9" (135 - 145 cm) | 24/26 inches
- 5 feet+ (145 cm +) | 26 inches
---
Mountain Bikes Sizing Chart:
- Adult Height (Inches) | Frame Size (Inches) | Frame Size
- 4'10 - 5'2" | 13 - 14" | X-Small
- 5'2 - 5'6" | 15 - 16" | Small
- 5'6 - 5'10" | 17 - 18" | Medium
- 5'10 - 6'1" | 19 - 20" | Large
- 6'1 - 6'4" | 21 - 22" | X-Large
- 6'4 - 6'6" | 22 - 24" | XX-Large
---
Road Bikes Sizing Chart:
- Adult Height (Inches) | Frame Size (Centimeters) | Frame Size
- 4'10 - 5'2" | 47 - 48 cm | XX-Small
- 5'2 - 5'6" | 49 - 50 cm | X-Small
- 5'3 - 5'6" | 51 - 53 cm | Small
- 5'6 - 5'9" | 54 - 55 cm | Medium
- 5'9 - 6'0" | 56 - 58 cm | Large
- 6'0 - 6'3" | 58 - 60 cm | X-Large
- 6'3 - 6'6" | 61 - 63 cm | XX-Large
---
Whether you're a seasoned rider or just starting out, we're committed to helping you find the perfect fit. Remember, the right size bike makes all the difference in your riding experience.
